The META POWER TR V4 is our most versatile ebike. It's capable of climbing the most demanding trails thanks to its excellent geometry, 29-inch wheels and powerful BOSCH Performance CX motor. On the descent, you'll find COMMENCAL's DNA: a healthy bike that's easy to handle.
The META POWER TR V4 BOSCH ÖHLINS EDITION showcases the performance of ÖHLINS suspension. • An RXF 36 Air fork features an air spring equipped with Ramp Up Chamber which allows for fine-tuning. The hydraulic cartridge offers high and low speed adjustments as well as rebound damping. The TTX Air shock is clean and dynamic. It has been designed to best adapt to our kinematics. • For a clean feel, stopping power is provided with SHIMANO XT 4-piston brakes and 220mm discs. • High-end DT SWISS HX1700 aluminium wheels are specifically designed for e-MTB use and hand-assembled by the Swiss brand. Strong and reliable. • A robust and reliable SHIMANO XT 12-speed drivetrain completes the build
Your enquiry has been recieved by a member of the Hyside Motorcycles Ltd team and they will get back to you within 24 hours
×Frame
Frame
META POWER TR V4, 140 mm 29", Alloy 6066, triple butted tubes, T4, T6.
Bar
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI LONGNECK Soft compound, single clamp, black
Seatpost
KS Lev Integra 31.6 mm, travel: 125 mm on S, 175 mm on M/L, 200 mm on XL, SouthPaw alloy remote
Saddle
FIZIK Terra Aidon X3 145 mm width, Kium Mobius rails
Pedals Included
RIDE ALPHA CNC
Performance
Battery
BOSCH PowerTube 625, 625Wh BOSCH 4A Charger, Compact size & lightweight Compatible w/BOSCH PowerMore 250 for extra range
Brakes
Brakes
SHIMANO XT, 4 pistons, resin pads, I-Spec EV compatible Rotors: SHIMANO SM-RT66 220 mm, 6-bolt
Suspension
Shock
OHLINS TTX22 Air 210 x 55 mm, climb mode, LSC, 3 positions HSC, rebound
Fork
OHLINS RXF36 m.2 Air, 150 mm travel 29", TTX 18 damper, climb mode, LSC, 3 positions HSC, rebound, Boost (15 x 110 mm), 44 mm offset
Chain Guide
RIDE ALPHA Upper Guide 32-34t
Dimensions
Weight
23.8 kg / 52.5 lb Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
